 Product Your Position：Home >> Product >> SMD Power Inductor >> FLQH Series
Type Photo Structure Dimension
L/W/H(mm)		 Inductance
Range(uH)		 Rated Current PDF
L W H Min(uH) Max(uH) IMin(A) IMax(A)
FLQH3216 unshielded 3.2 2.3 1.8 1.0 100 0.08 0.65
FLQH3225 unshielded 3.2 2.5 2.0 1.0 470 0.065 1.00
FLQH4532 unshielded 4.5 3.6 2.6 1.0 470 0.09 1.08
FLQH5750 unshielded 5.7 5.0 4.7 1.0 390 0.55 9.00
FLQH201610 shielded 2.0 1.6 1.0 0.24 10 0.45 3.20
FLQH252010 shielded 2.5 2.0 1.0 0.47 47 0.28 2.35
FLQH252012 shielded 2.5 2.0 1.2 0.47 22 0.38 2.15
FLQH3010 shielded 3.0 3.0 1.0 1.0 56 0.21 1.40
FLQH3012 shielded 3.0 3.0 1.2 0.22 100 0.21 3.00
FLQH3015 shielded 3.0 3.0 1.5 0.5 150 0.18 2.60
All 25 Records   Now1/3 Prev  1   2   3  Next
