 Product Your Position：Home >> Product >> SMD Power Inductor >> HLQH Series
Type Photo Structure Dimension
L/W/H(mm)		 Inductance
Range(uH)		 Rated Current PDF
L W H Min(uH) Max(uH) IMin(A) IMax(A)
HLQH201610 shielded 2.0 1.6 1.0 0.24 10 0.65 3.65
HLQH201612 shielded 2.0 1.6 1.2 0.24 4.7 1.25 4.50
HLQH252010 shielded 2.5 2.0 1.0 0.33 10 0.80 3.50
HLQH252012 shielded 2.5 2.0 1.2 0.24 22 0.45 4.05
HLQH3010 shielded 3.0 3.0 1.0 10 10 1.00 1.00
HLQH3012 shielded 3.0 3.0 1.2 0.33 15 1.00 4.20
HLQH4010 shielded 4.0 4.0 1.0 4.7 10 1.40 1.85
HLQH4012 shielded 4.0 4.0 1.2 0.33 22 0.90 4.30
HLQH4020 shielded 4.0 4.0 2.0 0.22 10 2.00 8.20
All 9 Records   Now1/1 Prev  1  Next
